IP55
IP Ratin
≤4000
Altitude (m)
5015.9
Rated Energy (kWh)
Battery Type
SHS180-314
Configuration
12P416S
Rated Voltage (Vdc)
1331.2
Operating Voltage Range (Vdc)
AC Side
Our Core Values
AC Side
Rated AC Power (kW)
450*6
Rated AC Voltage (Vac)
690
Adjustable range of reactive power
-1%~+1%
Rated Frequency (Hz)
50/60
Maximum efficiency
87.5%
General Parameters
Dimensions (W*D*H)
6058×2438×2896mm
Weight (kg)
0%RH~95%RH (non-condensing)
Operating Humidity
0%RH~95%RH (non-condensing)
Operating Temperature
-30°C ~55°C
Communication mode
Ethernet, RS485
Cooling Method
Smart Liquid Cooling
Fire Suppression System
Temperature sensing, smoke sensing, combustible gas detection, cabin level aerosols (thermosensitive starting), ventilation system, water fire protection
Certifications
IEC 62619:2022,IEC63056:2020,EN 62477-1:2022,IEC 60730-1:2022, EN 61000-6-2:2016, EN 61000-6-4:2018,IEC 62933-5-2,EN 301 489-1/-52, EN 301 908-1/-13,EN 62311,UN38.3
