This Movable Lithium Battery Pack is specially developed for residential energy storage scenarios. Equipped with a touch LCD display and an intelligent BMS (Battery Management System), it enables real-time monitoring of battery status. It supports multiple communication protocols including RS485, RS232 and CAN, featuring a design life of up to 15 years and a maximum cycle life of 6,000 times. The system allows up to 6 units to operate in parallel for flexible capacity expansion, and is compatible with mainstream inverters of various brands with excellent adaptability. Its wheeled base facilitates easy mobile deployment, delivering a safe, stable and easy-to-install energy storage solution for household backup power, off-grid power supply and other applications.
IP21
IP Rating
135KGS
Weight
16076Wh
Storage Capacity
Type of batter
Solid LFE
Capacity
314Ah
Battery Cycle Life
6000
Modular Structure
COMPREHENSIVE PARAMETERS
Our Core Values
COMPREHENSIVE PARAMETERS
MODEL
MB 512314
Battery Voltage
40V~58.4V
Colour
White
External Dimension
900*570*420mm
Warranty
5 Years
Maximum Altitude
3000m
OVERALL CHARACTERISTIC
Capacity for assembled cell discharging by 0.2C
≥314Ah
Standard Charge Condition
200A
Maximum Charge Current
200A
Maximum Discharge Current
≤80mΩ Assemblage Impedance
Internal Resistance
≥6000@25℃,80%EOL
Cycle Life
0℃~50℃
Recommend Charging Temperature
-15℃~50℃
Recommend Discharging Temperature
0-90%
Storage Temperature
Humidity
FUNCTIONAL CONFIGURATION
LED Panel (Light Emitting Diode)
YES
Communication
RS485,CAN,RS232
Parallel Capability
Up to 6 units
LED Power Display
Trac Light Display
BMS Control
Control Battery Performance
Package Size
1010*571*733mm (Carton)
CERTIFICATION
Safety
IEC62109-1, IEC62109-2,UL1741
EMC
EN61000-6-1, EN61000-6-3, FCC 15 class B
RoHS
Yes
