1kWh
Capacity
8000
Cycles
5Y
Warranty
Product Dimensions (mm)
276*185*199mm
Packaging Dimensions (mm)
360*225*290mm
Net Weight (kg)
10KG
Gross Weight (kg)
AC Input and Display Function
Our Core Values
AC Input and Display Function
Input Mode
Single-phase two-wire(L/N)
Output Voltage Waveform
Pure sine wave
Rated Voltage
230Vac
Voltage Range
90–280Vac ±5V
Frequency Range
45-65Hz
Power Factor
>0.95
Frequency Range
500W MAX
Power Factor
Pin Zi with Lid Male Head*1
LED Indicator Light
4 SOC power indicators, 1 working status indicator
LED Power Indicator
25/50/75/100%
PV Input and Environment
Nominal Photovoltaic Voltage
30V
Voltage Range
10A
Maximum Current
10A
(MPPT)Maximum Power (MPPT)
300W
Input Port
XT90E-M带盖cover*1
Operating Temperature
-10°C~50°C
Storage Temperature
-15°C~60°C
Humidity
20%-95% RH without condensation
Altitude
≤3000m,derating 1%/100m when>3000m
Noise(dB)
<40dB(1 meter)
AC Output and Protection Function
Output Mode
Single-phase two-wire
Rated Voltage
230Vac ±5V
Rated Frequency
50Hz+0.5%
Total Harmonic Distortion (THD)
<3% line/<5% nonline
Power Factor
≥0.99
Full Load Power
500W
UPSSwitching Time
≤20ms
Maximum Inverter Efficiency
88%
Output Port
National standard five hole socket*2
Undervoltage/Overvoltage Protection/Short Circuit Protection/Over-temperature Protection
Yes
DC Output and Solid Battery
Output Mode
5V/12V
Output Current
2A
Maximum Output Power
24W Max
THD Output Port
USB*3
Rated Voltage
32V
Voltage Range
2.9-3.65V
Typical Capacity
314Ah
Capacity
1004.8Wh
Maximum Charging Current
140A
Maximum Charging Power
500W
